63×33mm EM4425 (EM|echo-V) Dual-Frequency RFID Label:
- Dual-Frequency Operation: HF 13.56 MHz + UHF 860-960 MHz.
- Versatile Chip: EM echo-V (EM4425).
- Compliance: Meets ISO/IEC 18000-6C, EPC Gen-2, ISO15693, and NFC Tag Type 5 protocols.
- Robust Tracking: PET-faced label with 3M adhesive for durable and interactive capabilities.
- Ideal for: Asset management, customer engagement, inventory management, and anti-counterfeiting.
Features:
- Frequency Band: Dual-band HF 13.56 MHz + UHF 860-960 MHz.
- Chip Type: EM echo-V (EM4425).
- International Standard: ISO/15693, NFC Forum Type 5, ISO/IEC 18000-6C, EPC Global Gen 2v2.
- EPC Memory: 480 bits.
- User Memory: 2048 bits.
- Certificate: WEEE compliant.
Specifications:
Physical Specifications:
- Material: PET.
- Label Size: 63×33 mm.
- Antenna Size: 60×30 mm.
Technical Parameters:
- Operating Frequency: 13.56 MHz, 860-960 MHz.
- Communication Protocol: ISO/IEC 15693, NFC Forum Type 5, ISO/IEC 18000-6C, EPC Global Gen 2v2.
- Read Range: UHF: Up to 6.5 meters | NFC: Up to 4 cm.
- Operating Mode: Passive.
Additional Information:
Operating Limits:
- Temperature: -40°C to +70°C.
- Humidity: 20% to 90% RH.
Storage Limits:
- Temperature: -40°C to 28°C.
- Humidity: 40% to 60% RH.
Handling Precautions:
- Do not bend.
- Keep away from water and collision.
Chip Characteristics:
- Chip Manufacturer: EM.
- Chip Type: EM echo-V (EM4425).
- Data Retention: 50 years.
- EPC Memory: 480 bits.
- User Memory: Configurable shared memory of 2048 bits for both LF and UHF.
- Optional Digital Signature: None, 256b, 384b, 512b.
- TID Memory: 64 bits HF UID | 96 bits UHF TID.
- Write Endurance: 100,000 cycles.
- Capacitor: 50 pF.
- Read Sensitivity: -18 dBm.
- Write Sensitivity: -12.5 dBm.
Packaging:
- Packing Format: Packed in rolls, vacuum-sealed in ESD bags.
- Packing Quantity: 2000 pcs/roll.
Applications:
- Tamper-Evident Label: For inventory management and anti-counterfeiting.
- Heat Press Interactive NFC Garment Badge: Compact badge with a diameter of 25 mm, made from durable silicon, embedded with an EM4425 NFC+UHF dual-frequency chip for seamless interaction between clothing and reading devices.
Why Choose Us:
- Quality & Value: Over a decade as a leading RFID hardware manufacturer, delivering high-quality products at competitive prices.
- Expertise & Innovation: Our expert team provides advanced and customized RFID solutions.
