Features of Alien H9 RFID Windshield Label
- Frequency Band: UHF 860-960 MHz
- Chip Type: Alien H9
- International Standards: ISO/IEC 18000-6C, GS1 Class 1 Gen 2
- EPC Memory: 96-496 bits
- User Memory: 688 bits
- Read Range: Up to 13 meters
Physical Specifications
- Material: PET + 3M adhesive
- Label Size: 110×45 mm
- Inlay Size: 93×19 mm
Technical Parameters
- Operating Frequency: 860-960 MHz
- Communication Protocol: ISO/IEC 18000-6C, GS1 Class 1 Gen 2
- Antenna Etching Mode: Aluminum etching (10µm) + PET (50µm)
- Operating Mode: Passive
- IC ESD Voltage Immunity: 2000V (HBM)
- Read Range: Up to 13 meters
Chip Characteristics
- Chip Manufacturer: Alien
- Chip Type: H9
- Nonvolatile Memory: 1024 bits
- Unique TID: 48 bits (read-only)
- EPC Memory: 96-496 bits (read & write)
- User Memory: 688 bits (read & write)
- Access Password: 32 bits (read & write)
- Kill Password: 32 bits (read & write)
- Read Sensitivity: -20 dBm
- Write Sensitivity: -18 dBm
- Write Endurance: 200,000 write cycles
- Data Retention Time: 50 years
Additional Information
- Operating Environment: -20°C to 50°C, 20% to 80% RH
- Storage Environment: 18°C to 28°C, 40% to 60% RH
- Handling Precautions:
- Do not bend.
- Keep away from water and collision.
Packaging
- Packing Format: In roll, packed in ESD bag
- Roll OD Size: Max. 170 mm
- Core ID: 3 inches (76.20±0.50 mm)
- Packing Quantity: 1000±2 pieces per roll, 4 rolls per carton
