Product Overview
- Optimize your inventory management with our advanced 50x50mm UHF RFID Label.
- Powered by the U9 chip and fully compliant with ISO 18000-6C standards.
- Delivers reliability and high performance for your inventory tracking needs.
Features
- Frequency Band: UHF 860-960 MHz
- Chip Type: U9
- International Standard: ISO/IEC 18000-6C, EPC Global Gen 2v2.1
Specifications
Physical Specifications
- Material: Coated Paper
- Size: 50×50 mm
- Antenna Size: 44×44 mm
Technical Parameters
- Operating Frequency: 860-960 MHz
- Communication Protocol: ISO/IEC 18000-6C, EPC Global Gen2v2.1
- Operating Mode: Passive
Chip Characteristics
- Chip Manufacturer: Contact Customer Service
- Chip Type: U9
- Data Retention: 20 years
- EPC Memory: 96 bits
- TID Memory: 96 dBm
- Write Endurance: 100,000 cycles
- Kill Password: 32 bits
- Encoding Speed: 32 bits in 0.96 ms
- Read Sensitivity: -24 dBm
- Write Sensitivity: -22 dBm
Additional Information
- Operating Environment:
- Label Attach: 10°C~40°C, 20%~80% RH
- After Label Attached: -20°C~50°C, 20%~80% RH
- Storage Environment:
- Temperature: 18°C~28°C
- Humidity: 40%~60% RH
- Handling Precautions:
- Do not bend.
- Keep away from water and collision.
- Inlays with black-dot marks are defective; do not use.
Packaging
- Packing Format:
- Packed in roll, vacuumed packing in ESD bag
- Roll OD: Max. 8.27 inches (210 mm)
- Core ID: 3 inches (76.2 mm)
- Packing Quantity: 2000 pcs/roll (1.5 kg/roll)
