Product Overview
- NFC TAG424 DNA TagTamper provides AES-128 cryptographic operations.
- Offers advanced anti-counterfeiting and tamper-proofing features.
- Enables direct engagement between brand owners and consumers.
- Suitable for applications requiring high security and brand protection.
Features
- Frequency Band: HF 13.56 MHz.
- Chip Type: NFC TAG424 DNA TagTamper.
- International Standard: ISO/IEC 14443-A, NFC Forum Type 4.
- User Memory: 416 bytes.
- Read Range: Up to 10 cm.
- Certificate: WEEE compliant.
Technical Parameters
- Operating Frequency: HF 13.56 MHz.
- Communication Protocol: ISO/IEC 14443-A, NFC Forum Type 4.
- Read Range: Up to 10 cm.
- Internal Tuning Capacitance: 50 pF.
- Operating Mode: Passive.
Chip Characteristics
- Manufacturer: Contact Customer Service.
- Chip Type: Contact Customer Service 424 DNA TagTamper.
- Data Retention: 50 years.
- EEPROM Memory: 416 bytes.
- UID Memory: 7 bytes.
- Write Endurance: 100,000 cycles.
- ECC-based Originality Signature: Supported.
- AES-based Originality Keys Leveraging The LRP Wrapped AES Authentication: Supported.
- Secure Unique NFC (SUN) Message: Supported.
- Five Customer Defined AES 128-bit Keys: Supported.
Physical Specifications
- Material: Coated Paper + 3M adhesive.
- Size (L×W×T): 49×24×0.2 mm.
- Antenna Size: Diameter 21 mm.
Operating Environment
- Operating Temperature: -40°C to 70°C.
- Operating Humidity: 20% to 80% RH.
- Storage Temperature: 18°C to 28°C.
- Storage Humidity: 40% to 60% RH.
Handling Precautions
- Do not bend.
- Keep away from water and collision.
- Labels with black-dot marks are defective and should not be used.
Packaging
- Packing Format: Packed in roll, vacuum-sealed in ESD bag.
- Roll OD: Maximum 6.1 inches (155 mm).
- Core ID: 3 inches (76.2 mm).
- Packing Quantity: 100 pieces per roll (0.1 kg per roll).
Tamper-Evident RFID Label
- Available ICs: NFC TAG TagTamper.
- IC Options: NFC TAG 213 TagTamper and NFC TAG 424 DNA TagTamper.
- Both ICs feature a novel tamper evidence function for identification of tampering attempts.
