ISO/IEC 7810 Identification Cards Physical Characteristics

ISO/IEC 7810 (RFID) Identification playing cards Bodily traits is certainly a worldwide customary that defines the bodily traits for (RFID) identification playing cards. It’s the explanation for ISO/IEC 7810:2003 to produce standards that (RFID) playing cards shall carry out and in addition to specify the wants for such playing cards employed for worldwide interchange.

The choices specified outlined RFID card Bodily dimensions, which are varied sizes of identification playing cards having a nominal thickness of 0.76 mm :

ID-000 specifies a dimension of 25 mm * 15 mm, with the nook barely (3mm) bevelled. The ID-000 dimension was initially primarily based on ENV 1375-1, Identification card systems-Intersector built-in circuit(s) card extra codecs Half 1: ID-000 card dimension and bodily traits.

The ID-1 format specifies a dimension 85.60 * 53.98 mm (3 3/8 in * 2 1/8 in) and rounded corners having a radius of two.88-3.48 mm (about 1/8 in). It’s usually employed for fee playing cards (loyalty playing cards, RFID playing cards, atm RFID card, and so forth.). Immediately it’s additionally employed for driving licences in numerous nations. This format will also be employed for private identification playing cards in sure nations, automated fare assortment system playing cards for trains and buses.

The ID-2 format specifies a dimension 105*74 mm (4.134 * 2.913 in). This dimensions are the A7 format. The ID-2 format has employed for in French and Romanian identification card, and it was additionally utilized by the German identification card issued till October 2010.

ID-3 specifies a dimension 125 * 88 mm (4.921 * 3.465 in). This dimensions are the B7 format. This format is mostly employed for passport booklets.

The opposite specs of ISO/IEC 7810 specified embody:

-conditions for RFID card conformance

-the scale and tolerances from the RFID playing cards

-the improvement and supplies from the identification playing cards and the bodily traits from the playing cards for instance bending stiffness, flammability, toxicity, potential to take care of chemical compounds, dimensional stability, adhesion or blocking, warpage, potential to take care of warmth, floor distortions.
